Focusing lenses > Plane concave lens >

Plano-concave lens

Applications in Laser Technology

✅ Beam Expansion:

Paired with convex lenses to adjust beam size.

✅Collimation Correction:

Corrects divergent laser beams for optimized system alignment.

✅ Beam Shaping:

Used in homogenization or specific mode distribution designs.

Core Application Scenarios
Laser System Key Components
Application field	Technical Advantages	Typical Use Cases
Laser Beam Expansion	Enhances spot size and energy density uniformity	LiDAR systems
Beam Shaping	Eliminates high-order aberrations, optimizes pulse profiles	Ultrafast laser processing equipment
Laser Ranging	Controls divergence angle for long-range detection	Autonomous vehicle obstacle recognition
Fiber Coupling	Low insertion loss (<0.3 dB)	Optical communication transceiver modules


Selection Guidelines
Parameter Matching:	Select coating types (AR/HR) based on laser wavelength (e.g., 1064 nm/532 nm) and power level.
Customization:	Supports custom asphericity (≥λ/4 @632.8 nm) and special curvature radii (R ≥5 mm).
Quality Certification:	Manufacturing compliant with ISO9001 & MIL-PRF-13830B standards.


Key Highlights

Precision Focus:	Technical advantages align with industry-specific demands (e.g., LiDAR, ultrafast lasers).
Flexibility:	Tailored solutions for complex optical requirements.
Reliability:	Certified production ensures consistency and durability.



Optimized for performance, engineered for precision – empowering next-generation laser technologies.
